• Robust industrial features including –40 °C to +85 °C temperature range and versatile UART control (auto flow, fractional baud, deep FIFO).
• Seamless compatibility across Windows and Linux platforms with sleep/wake support for reliable server and embedded applications.
Specification
• PCIe 2.0 Gen 1 compliant
• x1 Link, dual simplex, 2.5 Gbps in each direction
• 15 KV ESD protection for all serial ports
• Sleep mode with wake-up Indicator
• Transmission media: twisted-pair cable or shielded cable
• Direction control: Adopt the technology which automatically controls the data-flow direction、automatically distinguish and control the data-transmission direction;
• Eight independent UART channels controlled with
• 16550 compatible register Set
• 256-byte TX and RX FIFOs
• Programmable TX and RX Trigger Levels
• TX/RX FIFO Level Counters
• Fractional baud rate generator
• Automatic RTS/CTS or DTR/DSR hardware flow control with programmable hysteresis
• Automatic Xon/Xoff software flow control
• UART interface support for 7 or 8 data bits,1 or 2 stop bits and even/odd/mark/space/none
• Flow control none,hardware and xon/xoff
• Extended operating temperature range; -40 to 85⁰C
System Requirements
• Windows OS
• Linux 2.6.27, 2.6.31, 2.6.32, 3.x.x and newer
• A available mini PCI Express slot
Applications
• Next generation Point-of-Sale Systems
• Remote Access Servers
• Storage Network Management
• Factory Automation and Process Control
